RANGER 1000 Premium Specifications
Engine & Drivetrain
Cooling
Liquid
Cylinders Displacement
999 cc
Drive System Type
Selectable on-demand all-wheel drive, AWD/2WD/VersaTrac Turf Mode
Engine Type
4-stroke twin cylinder SOHC
Fuel System/Battery
Electronic Fuel Injection
Horsepower
61
Transmission/Final Drive
Gen 2 Automatic PVT H/L/N/R/P; shaft
Dimensions
Bed Box Dimensions (L x W x H)
36.7 x 54.2 x 12.5" (93 x 138 x 32 cm)
Box Capacity
1,000 lbs. (454 kg) CA Models: 600 lbs. (272 kg)
Curb Weight
1,697 lbs. (770 kg)
Estimated Dry Weight
1,572 lbs. (713 kg)
Fuel Capacity
11.35 gal (43 L)
Ground Clearance
12.5" (31.8 cm)
Hitch Type
Standard 2" (5 cm) receiver
Overall Vehicle Size (L x W x H)
120 x 62.5 x 78" (305 x 159 x 193 cm)
Payload Capacity
1,500 lbs. (680 kg) CA Models: 1,100 lbs. (499 kg)
Person Capacity
3
Towing Capacity
2,500 lbs. (1,134 kg)
Turning Radius
13.3 ft (4.1 m)
Wheelbase
81" (206 cm)
Brakes
Front/Rear Brakes
4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers
Parking Brake
Park in-transmission
Technology
Audio System
Not equipped, accessory options available
Connected Vehicle Services
Not equipped, accessory options available
Touch Screen Display
Not equipped, accessory options available
Wheels & Tires
Front Tires
26 x 9-12; PXT 2.0
Rear Tires
26 x 11-12; PXT 2.0
Tire Ply Rating
6-Ply
Wheels
12" aluminum
Suspension
Front Suspension
Dual A-arm, 10" (25.4 cm) travel
Rear Suspension
Dual A-arm, 10" (25.4 cm) travel
Exterior Features
Cargo System
Gas-assist dump box with Lock & Ride accessory integration
Door Type
Cab nets
Vehicle Protection
Large steel bumper, full-coverage skid plate, A-arm guards
Winch
4,500 LB Winch with synthetic rope, Auto Stop and wireless remote
Lighting & Electrical
Electrical System
660-W charging system, Polaris Pulse electrical system (3-position), 12V accessory outlet, battery trickle-charging port
Lighting
Dual LED headlights, 600-lm low beam, 1,000-lm high beam, dual LED taillights
Comfort & Convenience
Cab Components
Roof
Driver Instrumentation
4" LCD rider information center: user selectable blue/red backlighting and brightness, programmable service intervals, speedometer, tachometer, odometer, tripmeter, clock, hour meter, gear indicator, fuel gauge, coolant temperature, voltmeter, service indicator and codes, seat belt reminder
Electronic Power Steering
High-output EPS
Seat Type
3-person bench seat with 3-point harness and adjustable driver seat
Speed Limiting
Not equipped, accessory options available
Steering
Tilt adjustment
