RANGER CREW 1000 Specifications
Engine & Drivetrain
Cooling
Liquid
Cylinders Displacement
999 cc
Drive System Type
Selectable on-demand all-wheel drive, AWD/2WD/VersaTrac Turf Mode
Driveline Features
Not equipped
Engine Type
4-stroke twin cylinder DOHC
Fuel System/Battery
Electronic Fuel Injection
Horsepower
61
Transmission/Final Drive
Gen 2 Automatic PVT H/L/N/R/P; shaft
Dimensions
Bed Box Dimensions (L x W x H)
36.7 x 54.2 x 12.5" (93 x 138 x 32 cm)
Box Capacity
1,000 lbs. (454 kg) CA Models: 600 lbs. (272 kg)
Estimated Dry Weight
1,723 lbs. (782 kg)
Fuel Capacity
11.35 gal (43 L)
Ground Clearance
12" (30.5 cm)
Hitch Type
Standard 2" (5 cm) receiver
Overall Vehicle Size (L x W x H)
152 x 62.5 x 76" (386 x 158 x 191 cm)
Payload Capacity
1,700 lbs. (771 kg) CA Models: 1,350 lbs. (612 kg)
Person Capacity
6
Towing Capacity
2,500 lbs. (1,134 kg)
Turning Radius
17 ft (5.2 m)
Wheelbase
113" (287 cm)
Brakes
Front/Rear Brakes
4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers
Parking Brake
Park in-transmission
Technology
Audio System
Not equipped, accessory options available
Connected Vehicle Services
Not equipped, accessory options available
Rear Camera
Not equipped
Security
Not equipped
Touch Screen Display
Not equipped, accessory options available
Wheels & Tires
Front Tires
25 x 10-12; Carlstar 489
Rear Tires
25 x 11-12; Carlstar 489
Tire Ply Rating
N/A
Wheels
12" steel
Suspension
Front Suspension
Dual A-arm, 10" (25.4 cm) travel
Rear Suspension
Dual A-arm, 10" (25.4 cm) travel
Exterior Features
Cargo System
Gas-assist dump box with Lock & Ride accessory integration
Vehicle Protection
Full-coverage skid plate, A-arm guards
Winch
Not equipped, accessory options available
Lighting & Electrical
Electrical System
660-W charging system, Polaris Pulse electrical system (3-position), 12V accessory outlet, battery trickle-charging port
Lighting
Halogen headlights, 55-W low beam, 60-W high beam, dual LED taillights
Comfort & Convenience
Cab Components
Not equipped
Driver Instrumentation
4" LCD rider information center: user selectable blue/red backlighting and brightness, programmable service intervals, speedometer, tachometer, odometer, tripmeter, clock, hour meter, gear indicator, fuel gauge, coolant temperature, voltmeter, service indicator and codes, seat belt reminder
Electronic Power Steering
Not equipped
Heat and/or Air Conditioning
Not equipped
Seat Type
6-person, dual-row bench seats with 3-point harness
Speed Limiting
Not equipped, accessory options available
Steering
Tilt adjustment
61
HP
62.5"
WIDTH
12"
GROUND CLEARANCE
