RANGER CREW XP 1000 CAB Specifications
-
RANGER XP 1000 Premium
-
RANGER CREW XP 1000 Premium
-
RANGER XP 1000 NorthStar Edition Premium
-
RANGER CREW XP 1000 NorthStar Edition Premium
-
RANGER XP 1000 NorthStar Edition Ultimate
-
RANGER CREW XP 1000 NorthStar Edition Ultimate
-
RANGER XP 1000 NorthStar Trail Boss Edition
-
RANGER CREW XP 1000 NorthStar Trail Boss Edition
-
RANGER XP 1000 CAB
Avalanche Gray
-
RANGER CREW XP 1000 CAB
Avalanche Gray
Engine & Drivetrain
Cooling
Liquid
Cylinders Displacement
999 cc
Drive System Type
Selectable on-demand all-wheel drive, AWD/2WD/VersaTrac Turf Mode
Driveline Features
N/A
Engine Type
4-stroke twin cylinder DOHC
Fuel System/Battery
Electronic Fuel Injection
Horsepower
82
Transmission/Final Drive
Gen 2 Automatic PVT H/L/N/R/P; shaft
Dimensions
Accessory Weight
362 lbs. (164 kg)
Bed Box Dimensions (L x W x H)
36.75 x 54.25 x 12.5" (93 x 138 x 32 cm)
Box Capacity
1,000 lbs. (454 kg) CA Models: 600 lbs. (272 kg)
Estimated Dry Weight
2,060 lbs. (934 kg)
Fuel Capacity
11.5 gal (43.5 L)
Ground Clearance
14" (36 cm)
Hitch Type
Standard 2" (5 cm) receiver
Overall Vehicle Size (L x W x H)
152 x 65 x 79.5" (386 x 165 x 201 cm)
Payload Capacity
1,125 lbs. (510 kg)
Person Capacity
6
Towing Capacity
2,500 lbs. (1,134 kg)
Turning Radius
17.5' (5.3 m)
Wheelbase
113" (287 cm)
Brakes
Front/Rear Brakes
4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers
Parking Brake
Park in-transmission
Technology
Audio System
Not equipped, accessory options available
Connected Vehicle Services
Not equipped, accessory options available
Rear Camera
Not equipped, accessory options available
Security
Polaris P.A.S.S. anti-theft system
Touch Screen Display
Not equipped, accessory options available
Wheels & Tires
Front Tires
29 x 9-14; Pro Armor X Terrain
Rear Tires
29 x 11-14; Pro Armor X Terrain
Tire Ply Rating
8-ply
Wheels
14" aluminum
Suspension
Front Suspension
Dual A-arm, 10" (25.4 cm) travel
Rear Suspension
Dual A-arm, 10" (25.4 cm) travel
Exterior Features
Cargo System
Gas-assist dump box with Lock & Ride accessory integration
Door Type
Powered window front doors, crank window rear doors
Vehicle Protection
Large steel bumper, full-coverage skid plate, A-arm guards
Winch
Not equipped, accessory options available
Lighting & Electrical
Electrical System
140-amp charging system, Polaris Pulse electrical system (6-position hood and 6-position roof), USB charger, 12V accessory outlet, battery trickle-charging port
Lighting
Halogen Headlamps, 55W low beam, 60W high beam, Dual LED Taillamps
Comfort & Convenience
Cab Components
Factory-installed cab system with roof and sound insulation materials, fixed glass windshield, tinted rear panel, powered front windows, crank rear windows, windshield wiper/washer, dome light
Driver Instrumentation
Dual-sweep analog dials with 4" LCD rider information center: user selectable blue/red backlighting and brightness, passcode protection, programmable service intervals, speedometer, programmable speed limiting, tachometer, odometer, tripmeter, clock, hour meter, gear indicator, fuel gauge, coolant temperature, voltmeter, service indicator and codes, seat belt reminder
Electronic Power Steering
High-output EPS
Heat and/or Air Conditioning
Factory-installed heat, AC, defrost
Seat Type
6-person bolstered bench seats with 3-point harness
Speed Limiting
Speed limiting controlled in gauge
Steering
Tilt adjustment
82
HP
65"
WIDTH
14"
GROUND CLEARANCE
