RZR Trail S 1000 Ultimate Specifications
Engine & Drivetrain
Cooling
Liquid
Cylinders Displacement
999 cc
Drive System Type
High-performance true on-demand AWD/2WD
Driveline Features
Not equipped
Engine Type
4-stroke DOHC twin cylinder
Fuel System/Battery
Electronic Fuel Injection
Horsepower
100
Transmission/Final Drive
Automatic PVT P/R/N/L/H
Dimensions
Bed Box Dimensions (L x W x H)
20.7 x 37 x 7.9" (52.5 x 94 x 20 cm)
Box Capacity
300 lbs. (136.1 kg)
Estimated Dry Weight
1,377 lbs (625 kg)
Fuel Capacity
9.5 gal (35.9 L)
Ground Clearance
12.5" (31.8 cm)
Hitch Type
Standard 1.25" (3.2 cm) receiver
Overall Vehicle Size (L x W x H)
110.9 x 60 x 69.3" (282 x 152.4 x 176 cm)
Payload Capacity
740 lbs. (335.7 kg)
Person Capacity
2
Towing Capacity
1,500 lbs. (680 kg)
Wheelbase
79" (200.7 cm)
Brakes
Front/Rear Brakes
4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers
Parking Brake
Park in-transmission
Technology
Audio System
Rockford Fosgate® Stage 2 audio
Connected Vehicle Services
Not equipped
Rear Camera
Equipped
Security
Polaris P.A.S.S. anti-theft system
Touch Screen Display
7" Display, powered by RIDE COMMAND, featuring: built-in GPS, Group Ride (cell and non-cell communications), topographic mapping, Bluetooth and USB smartphone connectivity
Wheels & Tires
Front Tires
27 x 9-12"
Rear Tires
27 x 11-12"
Tire Ply Rating
6-Ply
Wheels
Cast aluminum
Suspension
Electronic Suspension Control System
Not equipped
Front Shocks
2" Walker Evans® needle shocks with 16-position adjustable clickers
Front Suspension
Dual A-arm with stabilizer bar and 12.25" (31.1 cm) wheel travel
Rear Shocks
2" Walker Evans needle shocks with 16-position adjustable clickers
Rear Suspension
Dual A-arm with stabilizer bar and 13.2" (33.5 cm) wheel travel
Exterior Features
Cargo System
Lock & Ride
Door Type
Half doors, roof
Vehicle Protection
Not equipped
Winch
Not equipped
Lighting & Electrical
Electrical System
560-W Charging System @ 6000 RPM, 3-Position Pulse Bar
Lighting
Signature RZR Fang Accent Lighting, signature white LED low/high Red LED tail/brake lights
Comfort & Convenience
Cab Components
Half doors, Poly roof
Drive Modes
Not equipped
Driver Instrumentation
Dual-sweep analog dials with 4" LCD rider information center: user-selectable blue/red backlighting & brightness, programmable service intervals, speedometer, tachometer, odometer, tripmeter, clock, hour meter, gear indicator, fuel gauge, coolant temperature, voltmeter, service indicator and codes, seat belt reminder light, gear indicator, DC outlet + 12V power plug
Electronic Power Steering
Equipped
Heat and/or Air Conditioning
Not equipped
Ride Control
Not equipped
Seat Type
Bolstered bucket seats with tool-less driver seat slider and standard passenger seat slider (tool required for adjustment on passenger seat)
Speed Limiting
Not equipped
Steering
Adjustable tilt steering
100
HP
60"
WIDTH
12.5"
GROUND CLEARANCE
