RZR Trail Ultimate Specifications
Engine & Drivetrain
Cooling
Liquid
Cylinders Displacement
875 cc
Drive System Type
High-performance true on-demand AWD/2WD/VersaTrac Turf Mode
Driveline Features
Yes
Engine Type
4-stroke DOHC twin cylinder
Fuel System/Battery
Electronic Fuel Injection
Horsepower
75
Transmission/Final Drive
Automatic PVT P/R/N/L/H
Dimensions
Bed Box Dimensions (L x W x H)
20.7 x 37 x 7.9" (52.5 x 94 x 20 cm)
Box Capacity
300 lbs. (136.1 kg)
Estimated Dry Weight
1,314 lbs. (596 kg)
Fuel Capacity
9.5 gal (35.9 L)
Ground Clearance
11" (27.9 cm)
Hitch Type
Standard 1.25" (3.2 cm) receiver
Overall Vehicle Size (L x W x H)
110.9 x 50 x 67.9" (282 x 127 x 172.5 cm)
Payload Capacity
740 lbs. (335.7 kg)
Person Capacity
2
Towing Capacity
1,500 lbs. (680 kg)
Wheelbase
79" (200.7 cm)
Brakes
Front/Rear Brakes
4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers
Parking Brake
Park in-transmission
Technology
Audio System
Rockford Fosgate® Stage 2 audio
Connected Vehicle Services
Not equipped
Rear Camera
Equipped
Security
Polaris P.A.S.S. anti-theft system
Touch Screen Display
7" Display, powered by RIDE COMMAND, featuring: built-in GPS, Group Ride (cell and non-cell communications), topographic mapping, Bluetooth and USB smartphone connectivity
Wheels & Tires
Front Tires
26 X 8 X 12"
Rear Tires
26 X 9 X 12"
Tire Ply Rating
3-Ply
Wheels
Cast aluminum
Suspension
Electronic Suspension Control System
Not equipped
Front Shocks
FOX® 2.0 PODIUM X
Front Suspension
Dual A-arm with stabilizer bar and 10" (25.4 cm) wheel travel
Rear Shocks
FOX® 2.0 PODIUM X
Rear Suspension
Dual A-arm with stabilizer bar and 10" (25.4 cm) wheel travel
Exterior Features
Cargo System
Lock & Ride
Door Type
Half doors, roof
Vehicle Protection
Not equipped
Winch
Not equipped
Lighting & Electrical
Electrical System
560-W Charging System @ 6000 RPM, 3-Position Pulse Bar
Lighting
Signature RZR Fang Accent Lighting, signature white LED low/high Red LED tail/brake lights
Comfort & Convenience
Cab Components
Half doors, Poly roof
Drive Modes
Not equipped
Driver Instrumentation
Dual-sweep analog dials with 4" LCD rider information center: user-selectable blue/red backlighting & brightness, programmable service intervals, speedometer, tachometer, odometer, tripmeter, clock, hour meter, gear indicator, fuel gauge, coolant temperature, voltmeter, service indicator and codes, seat belt reminder light, gear indicator, DC outlet + 12V power plug
Electronic Power Steering
Equipped
Heat and/or Air Conditioning
Not equipped
Ride Control
Not equipped
Seat Type
Bolstered bucket seats with standard driver and passenger seat sliders (tool required for adjustment on driver and passenger seat)
Speed Limiting
Not equipped
Steering
Adjustable tilt steering
75
HP
50"
WIDTH
11"
GROUND CLEARANCE
